Описание
Shaft & Wheel, Turbine Wheel / Турбинна перка, вал
GARRETT
A: 41.35 mm ; OUTER DIAMETER
B: 33.83 mm ; INNER DIAMETER
C: 7.41 mm ; FEEDER HEIGHT
D: 7.88 mm ; Shaft diameter bearing raceway
E: 5.08 mm ; FEEDER HEIGHT
OP1: SINGLE ; NUMBER OF RINGS [TWIN/SINGLE]
OP2: SLENDER ; ROLLER TYPE [SLENDER/STRAIGHT]
OP3: OPEN ; ROTOR TYPE (FULL/OPEN)
OP4: 9 ; Number of blades
452098-0002, 452098-0004, 452151-0004, 452202-0002, 702404-0001, 720244-0001 / 1100-020-002
452098-0001 452098-1 452098-2 452098-3 452151-0006 452151-2 452151-4 452151-6 452283-0001 452283-0002
GT1549 GT1549S
OEM Turbine
433298-32 434713-0007 452098-0002 452098-0004 452151-0002 452151-0004 452202-0003 452202-0004 452283-0003 702404-0002 702404-5002S 702404-2002S
720244-0001 720244-2001S 720244-5001S 720244-0002 720244-2002S 720244-5002S 720244-0004 720244-2004S 720244-5004S
720244-0002 720244-0003 720244-0004
OEM Code
1441100QAC 4404326 4506118 7701473023 7701473756 7711134676 7711134972 8200069567 8200100284 860095 9112326 9201600 93184463 PMF100400
PMF100440 PMF100450 PMF6105 R1630013
Dimensions
D1(mm): 33.8 D2(mm): 41.4 D5(mm): 7.88 D8(mm): 7.4 Blades: 9
