Описание
Shaft & Wheel, Turbine Wheel / Турбинна перка, вал
BMW E46 E53 E91 E61 E90 E64 E70 E83 E71 E72
Mercedes W31 S211 W639 W164 318CDI C219
GARRETT 1100-016-166B
Сериен номер на турбото:
742730-0001 , 742730-0003 , 742730-0004 , 742730-0007 , 742730-0013 , 742730-0015 , 742730-0018 , 742730-0019 , 743507-0009
742730-0001 GT22V 11657790308, 11657790308G, 7790306E, 7790306G, 7790308G, 7790308N
742730-0003 11657790308, 11657790308G, 11657790308L, 7790308G 742730-0004 11657790306G, 7790306G 742730-0007 11657790306J, 7790306J 742730-0013 11657790306L, 7790306L 742730-0015 11657790308L, 7790308L 742730-0018 11657790306G, 11657790306J, 11657790306L, 11657790308, 11657790308G, 11657790308L, 11657790308N, 7790306E, 7790306G, 7790308G, 7790308N 742730-0019 11657790306G, 11657790306J, 11657790306L, 11657790308, 11657790308G, 11657790308L, 11657790308N, 7790306E, 7790306G, 7790308G, 7790308N 743115-0001 6480960199, A6480960199 743115-0003 A6480960199
743507-0009 6420900080, 6420906980, A6420900080, A6420901480, A6420901580, A6420905980, A6420906980
A: 49.9 mm ; OUTER DIAMETER
B: 45.8 mm ; INNER DIAMETER
C: 9.4 mm ; FEEDER HEIGHT
D: 7.88 mm ; Shaft diameter bearing raceway
E: 5.08 mm ; FEEDER HEIGHT
OP1: TWIN ; NUMBER OF RINGS [TWIN/SINGLE]
OP2: STRAIGHT ; ROLLER TYPE [SLENDER/STRAIGHT]
OP3: OPEN ; ROTOR TYPE (FULL/OPEN)
OP4: 9 ; Number of blades
GT2260VK GTA2259VK GTA2359VK
OEM Turbine
742730-0001 742730-0003 742730-0004 742730-0007 742730-0013 742730-0015 742730-0018 742730-0019 743115-0001 743115-0003 743507-0009 451298-0009
742730-1 742730-3 742730-4 742730-7 742730-13 742730-15 742730-18 742730-19 743115-1 743115-3 743507-9 451298-9
742730-2001S 742730-2003S 742730-2004S 742730-2007S 742730-2013S 742730-2015S 742730-2018S 742730-2019S 743115-2001S 743115-2003S 743507-
2009S 742730-5001S 742730-5003S 742730-5004S 742730-5007S 742730-5013S 742730-5015S 742730-5018S 742730-5019S 743115-5001S 743115-5003S
743507-5009S 742730-9001S 742730-9003S 742730-9004S 742730-9007S 742730-9013S 742730-9015S 742730-9018S 742730-9019S 743115-9001S 743115-
9003S 743507-9009S
OEM Code
6480960199 11657790306 11657790308 7790306E 7.790.306-E 7790306G 7.790.306-G 7790306J 7.790.306-J 7790306L 7.790.306-L 7790308G 7.790.308-G
7790308L 7.790.308-L 7790308N 7.790.308-N A6420900080 A6480960199 A6840960199
Dimensions
D1(mm): 45.8 D2(mm): 49.9 D5(mm): 7.88 D8(mm):9.4 Blades: 9
